How To Adjust Your GPU’s Fan Speeds [Step-By-Step]

CG Director Author Christopher Harperby Christopher Harper   /  Updated

Ever wondered how to adjust your GPU’s fan speeds? You’ve come to the right place! Stick around and I’ll walk you through everything you need to know about adjusting your GPU’s fan speeds.

I’ll mainly be using MSI Afterburner for this guide, as it’s guaranteed to work regardless of your GPU provider, but I’ll also take a few moments to discuss other options of note before wrapping things up.

MSI Afterburner

Source: MSI

Let’s get into it! As always, feel free to skip around with the Table of Contents below if you like.

A Brief on GPU Cooling and Control

First, let’s take a quick moment to talk about GPU cooling in general. This article is for teaching you how to control a discrete GPU and its cooling.

For an integrated GPU (sharing a die with your CPU), solutions like Afterburner will be useless.

The most you can do in that scenario is improve your CPU cooling or disable the iGPU entirely, and even then the latter only works if you have an actual iGPU to use in its stead.

Most of the time, your GPU cooling will be fully automated without you, the end user, needing to think about it at all. Your GPU has a pre-set fan curve out of the box that should correspond to your GPU temperature.

GPU Cooler Design

Image Credit: NVIDIA

As your GPU temperatures rise, so too should your fan speeds in order to keep the card cool and prevent it from thermal throttling or, worse, overheating.

When your existing fan curve is insufficient to prevent overheating, or simply too loud at max throttle, is when you most want to use a guide like this one.

All that said…let’s begin!

How To Adjust Your GPU’s Fan Speeds (Main Method)

Step 1: Install MSI Afterburner

First, you’ll want to install MSI Afterburner. The usual process for this applies: download the ZIP, open the executable, launch it, click through the install process as usual.

You’ll get an option to install RivaTuner Statistics Server alongside it— I recommend doing so, since RTSS can give you an in-game overlay for showing your Afterburner hardware monitor metrics and is a very good solution for capping FPS in titles with poor or no FPS capping implemented.

Step 2: Launch, and Save The Default Profile

Once you’ve finished the installation process, go ahead and launch Afterburner.

Within Afterburner, click confirm that the Lock icon next to the Number buttons (corresponding to Profiles) is set to Unlocked. This should make the Save button at the bottom of the screen usable.

MSI Afterburner lock icon

Now, click Save.

MSI Afterburner profile 1

After clicking Save, click “1” in order to save these default MSI Afterburner settings as your default profile, should you want to return to them later.

Step 3: Adjust Fan Speed in MSI Afterburner

Now, this is where we get to the part you’re here for. Click the Gear icon to enter MSI Afterburner Properties.

MSI Afterburner gear icon properties

Click the “Fan” tab in Properties, and check the box that says “Enable user defined software automatic fan control”.

You’ll also want to click the dropdown beside “Predefined fan speed curve” and set it to “Custom”.

I’ve embedded a screenshot of this below:

MSI Afterburner Fan Speed Graph

Now, you can actually click and drag individual points on the fan speed curve graph as you please. Each “point” corresponds to a combined temperature and fan speed target.

The biggest difference will be noticeable by lowering the highest point since you’ll be effectively reducing your maximum fan speed.

I’ve embedded an example screenshot of this below:

MSI Afterburner Fan Speed capped at 74%

Note how my maximum fan speed is now capped at 74%! That should be a pretty fair noise reduction. You can adjust your targets as you like, just remember to click “Apply” before you close the Properties window.

Step 5: Save and Minimize Afterburner

Back in the main window, it’s time to click the Save button again. The numbered Profile buttons will flash when you do this.

MSI Afterburner main window - save

Click “2”, and this new, low-fan-speed profile we’ve created should be saved within Afterburner, separate from the default profile saved earlier.

MSI Afterburner profile 2

And you’re done!

Other Ways To Adjust GPU Fan Speed

While MSI Afterburner is the most popular solution for GPU fan speed control and overclocking, it isn’t the only option.

Let’s take a moment to talk about some other software you might want to use, instead.

AMD Radeon Software, WattMan

AMD WattMan

Image Credit: AMD

If you own an AMD graphics card, you may find that AMD actually has a shockingly in-depth panel for GPU fan speed and control within its default graphics driver software!

You can set custom profiles for overclocking or fan speed curves in WattMan just like you can with Afterburner.

The same concepts applied in the guide above should work fine here, too, though I’d advise some caution if you plan on doing GPU overclocking with WattMan or Afterburner.

Your GPU Manufacturer’s Control Software

AORUS Graphics Engine

Image Credit: Gigabyte

If you want to simplify your GPU controls a bit and don’t feel like adjusting fan curves and the such, you may still have options!

Many GPU vendors offer their own software tailored to your specific GPU model that you can acquire from your manufacturer’s GPU support/drivers/downloads page.

When the software is tailored for your exact GPU in this way, you can usually set stuff like “Silent Mode”, “Eco Mode”, etc in order to reduce your fan speeds and GPU utilization with a single button press.


Why Aren’t My GPU Fans Spinning?

Since GPU fans are the noisy part of your GPU and, besides the thermal paste, the part most likely to wear out over time due to wear-and-tear, many modern GPUs don’t even start the fans until a certain temperature threshold has been reached.

If your GPU fans still aren’t spinning when your GPU is under load is when you have a problem, though.

I’ve linked a full troubleshooting guide by Alex in the sentence above, should you find yourself in this scenario and are looking for a fix.

Will Higher Fan Speeds Make My GPU Faster?

In theory, yes! If your GPU remains cooler, it should take a more sustained heavy load to actually force it into a state where it needs to thermal throttle.

What is Thermal Throttling

However, this doesn’t necessarily mean your GPU will run faster. Higher fan speeds do mean lower temperatures, but your GPU isn’t going to surpass its own specs by being cooler.

Instead, it’ll be able to perform at its peak spec longer before needing to throttle to prevent overheating.

Will Slower Fan Speeds Make My GPU Slower?

Unfortunately, yes.

Since your GPU fans are responsible for directly cooling your GPU, you’re unlikely to be able to maintain stable GPU Boost frequencies for very long if you’re limiting your fan speed below its maximum.

Undervolting your GPU in addition to a GPU fan speed reduction should help you save some performance, though.

Is 100% Fan Speed OK on a GPU?

Of course! 100% Fan Speed is to be expected, unless you’re running at idle…in which case your GPU may just be overheating, in general, most likely due to expired thermal paste since your fans are ramping up without effectively cooling your graphics card in this scenario.

However, there are reasons to avoid running a GPU’s fans at 100%, especially if you find them particularly noisy or distracting at full load. By adjusting the fan curve as shown earlier in this article, you can effectively cap your maximum fan speed to whatever you want.

Over to You

And that’s it!

I hope this article helped you adjust your GPU’s fan speeds to your desired levels, and clarified the impact you can expect that to have on your performance.

Leave a comment below and let us here at CGDirector know if you need any more help with your GPU or PC hardware, and we’ll be happy to help!

Alternatively, you can also head to the CGDirector Forums to show off your current PC building or rendering projects, or just interact with the rest of the community! The choice is in your hands.

Until then or until next time, stay safe! And remember: lower fan speeds mean less noise, but less performance, too. Make these trade-offs wisely.

CGDirector is Reader-supported. When you buy through our links, we may earn an affiliate commission.

Christopher Harper

I have been a passionate devotee to technology since the age of 3, and to writing since before I even finished high school.

These passions have since combined into a living in my adulthood and have made writing about PC Hardware very satisfying.

If you need any assistance, leave a comment below: it’s what I’m here for.


Also check out our Forum for feedback from our Expert Community.

Leave a Reply

  • Gianluca

    Hi, sorry I don’t have the tab FAN in the MSI Afternurning.
    My pc is an All in one Modern ADL-P AM272 (MS-AF82), that is a little noisy even if nothign is running. Can you help me please?

    • Alex Glawion

      Havo you tried entering your BIOS to adjust your fan curves? The tool “Speedfan” may also be something you can try if Afterburner doesn’t work for you.
